| 品牌：GPS/北斗车载天线 | 型号：GPS/北斗车载天线 | 使用温度(℃)：-40-85 |
| 储存温度：-40-85℃ | 抗压强度(N)：1 | 抗拉强度(N)：1 |
| 适用范围：1 |
Item | Specifications | |
Antenna | Center Frequency | 1568±1MHz |
Band Width | CF±8MHz | |
Polarization | RHCP | |
Gain | 5dBic（Zenith） | |
V.S.W.R | ＜1.5 | |
Impendance | 50Ω | |
Axial Ratio | 3dB（max） | |
Dimension | 25*25*4mm | |
LNA | Gain | 28±2dB |
Noise Figure | ＜1.0 | |
Filter Insertion Loss | ＜3dB | |
Ex-band Attenuation | 35dB@CF±50MHz/50dB@CF±100MHz | |
Supply Voltage | 2.2~5V DC | |
Current Consumption | 16~32mA | |
V.S.W.R | ＜2.0 | |
